| 제품 | 파이프 피팅(티, 크로스, 엘보, 리듀서, 캡, 스텁 엔드) | |||||
| 표준 | ASTM A234, ASTM A350, ASTM A335, EN10253-2, EN 10253-3, EN 10253-4, ASTM A420, ASTM A860, ASTM A403, ASME B16.9, MSS SP-75, ASME B16.11, MSS SP-97, MSS SP-95, GB/T 12459, SH/T 3408, SH/T 3410, GB/T 14383, GB/T 35072 | |||||
| 재료 | 재료 등급 | 재료 기준 |
치수 | |||
| WPB、WPC、WP5、WP9、WP11、WP12、WP22、WP91 | ASTM A234 | DN15(1/2")~DN3600(144") | ||||
| LF2 | ASTM A350 | DN15(1/2")~DN3600(144") | ||||
| P5、P9、P12、P91 | ASTM A335 | DN15(1/2")~DN3600(144") | ||||
| P235TR1, P235TR2, P265TR1, P265TR2, P235GH, P265GH, 16Mo3, P355N, P355NH, L290NB, L360NB, L415NB | EN 10253-2 | DN15(1/2")~DN3600(144") | ||||
| 1.4301、1.4307、1.4401、1.4404、1.4541 | EN 10253-3、 EN10253-4 |
DN15(1/2")~DN3600(144") | ||||
| ST37.0、ST44.0、ST35.8 | DIN 2609-1 | DN15(1/2")~DN3600(144") | ||||
| WPL3、WPL6、WPL8 | ASTM A420 | DN15(1/2")~DN3600(144") | ||||
| WPHY 42、WPHY 46、WPHY 52、WPHY 60 WPHY 65、WPHY 70 |
ASTM A860 | DN15(1/2")~DN3600(144") | ||||
| WP304, WP304L, WP304H, WP316, WP316L, WP316H, WP316N, WP316TI, WP321, WP321H, WP347, WP347H, WP310, WP310S, WPS31254, WP317, WP317L, WP904, WP904L | ASTM A403 | DN15(1/2")~DN3600(144") | ||||
| CF370, CF415, CF415K, CF485, CF485K, AF11, AF11G, AF12, AF12G, AF14, AF22, AF22G, AF5, AF5G, AF9, AF9G, AF91, LF415K2, LF485K2, LF450K3, SF304, SF304L, SF316 SF316L、SF321、SF2225、SF2205、SF2507 |
GB/T 13401 | DN15(1/2")~DN1500(60") | ||||
| 20、16Mn、15CrMo、12Cr1MoV、12Cr2Mo1、20MnMo、12Cr5Mo、10Cr9Mo1VNbN | NB/T 47008 | DN6～DN100 | ||||
| 16MnD, 20MnMoD, 09MnNiD, 08MnNiCrMoVD | NB/T 47009 | DN6～DN100 | ||||
| 06Cr19Ni10/S30408, 022Cr19Ni10/S30403, 06Cr17Ni12Mo2/S31608, 022Cr17Ni12Mo2/S31603 06Cr18Ni11Ti/S32168、07Cr18Ni11Nb/S34779 |
NB/T 47010 | DN6～DN100 | ||||
| S31803、S32205、S32750、S32760、WP430 | ASTM A815 | DN15(1/2")~DN3600(144") | ||||
| WPHC276, NO8825, NO6625, MONEL 400/500, WPN, WPNL | ASTM B366 | DN15(1/2")~DN3600(144") | ||||
| ST35.8 | DIN 17175 | DN15(1/2")~DN3600(144") | ||||
| L245(B)、L290(42)、L320(X46)、L360(X52)、 L390(X56)、L415(X60)、L450(X65)、L485(X70) |
API 5L | DN15(1/2")~DN3600(144") | ||||
| UNS C70600、UNS C71500 | ASTM B466 | DN15(1/2")~DN3600(144") | ||||
| WPT1、WPT2、WPT3、WPT7、WPT9、WPT11、WPT12、WPT23 | ASTM B363 | DN15(1/2")~DN3600(144") | ||||
